SDR, SDR switch, and digirig

1

I am looking to see how to use an SDR, SDR switch, and digirig mobile together.

SDR switch
MFJ-1708B-SDR

SDR switch kit
SDR, ( Software Defined Radio ) RX Antenna Switch

I am using a Yeasu FT-920 with a digirig and my laptop PC. I have an SDRplay RSP1 and am using SDRuno.

I appreciate everyones help.

2

Do you have each of the two devices working separately?
Is there some conflict between the two devices when used together?

3

I have not yet connected everything together. I was asking in case others had encountered any issues. I will provide an update after everything is connected and let the forum know.

Thank you.

1 Like
4

I have the SDRPLAY, MFJ-1708B-SDR switch and my Yeasu FT-920 HF radio setup. It works really well.

The video below helped with connecting the Tx Gnd from the radio to the Control port on the MFJ-1708B-SDR

“SDRplay Panadapter Webinar” on YouTube

Since MFJ has gone out of business I would look at the following option

VE2DX SDR TR Switches

1 Like
5

Congratulations and thanks for reporting here.

73 Constrainted
