Which Digirig would you use for the Anytone D878UVII Plus? And which cables?
1 Like
You need the logic levels configured digirig: Digirig Mobile – digirig
See this post for cables: Cable for Anytone AT-D578UV III Pro & Plus
You can make/buy the audio-only cable for RTS PTT, or at the bottom of the post there’s an audio/serial cable that you can make that will support CAT PTT. I’m working with Hamlib to get the Anytone added to the library, it’s been added to VARA FM, and SoundModem. There’s more info about compatible software here: Home · jrobertfisher/AT-D578UV-software-mic Wiki · GitHub
I have been wanting to use my 878 with Winlink. I asked the Bridgecom folks at Hamvention and they told me they were working with Denis on getting it to work but that it’s not ready yet.
Your AT-878 works with Baofeng audio/PTT cable. More info in these posts:
I successfully used the Baofeng cable with an Anytone 878 on Winlink. I found that I had to increase the TX delay to 600, but it does work just fine.
1 Like
I made this video and hope it help!
Setting for Winlink on your Anytone 878 or 868, using VARA FM with a DIGIRIG interface.
IN VARA FM SETTING - YOU WILL NEED TO SELECT PTT METHOD BY RTS OF DIGIRIG’S COM PORT.
Step-by-step setup of Winlink on Anytone 878/868
Configuring VARA FM with DIGIRIG for efficient communication
Optimizing your setup for both Windows 10 and Windows 11
Setting for Winlink on your Anytone 878 or 868, using VARA FM with a DIGIRIG interface.
IN VARA FM SETTING - YOU WILL NEED TO SELECT PTT METHOD BY RTS OF DIGIRIG’S COM PORT.
